8.1.3 Recording test in HARK with radio RASP

Confirm the equipment prior to recording. Use equipment similar to that in table 8.1.

Table 8.1: List of devices to be used

Device name	Description
Wireless RASP	A/D, D/A conversion device
Router for wireless LAN	For connection between RASP and host PC
PC	PC to operate the radio

For a speech recording test with HARK, use the network file test.n shown in Figure 8.2. The connection route is from MatrixToMap to SaveRawPCM , from AudioStreamFromMic via ChannelSelector . Table 8.2 shows the setting for each property.

$>$ ./test.n

By setting the above, the speech of the analog input 1 of radio RASP is recorded for three seconds. Speech of PCM 16-bit quantization and 16kHz sampling is saved in the little endian RAW format.

$\includegraphics[bb=0 0 1200 800,width=120mm]{fig/device/WS-sample.png}$

Figure 8.2: Network (test.n)

Table 8.2: Properties of a speech recording network

Module name	Property name	Type of value	Set value
AudioStreamFromMic	LENGTH	`int`	512
	ADVANCE	`int`	160
	CHANNEL_COUNT	`int`	16
	SAMPLING_RATE	`int`	16000
	DEVICETYPE	`string`	WS
	DEVICE	`string`	192.168.0.1
ChannelSelector	SELECTOR	`Object`	$<$ `Vector` $<$ `int` $>$ 0 $>$
SaveRawPCM	BASENAME	`string`	sep
	ADVANCE	`int`	160
	BITS	`int`	16
Iterate	MAX_ITER	`int`	300
